Solving complex separation challenges often requires looking beyond the standard liquid chromatography column. In a recent Analytical Training Solutions (ATS) course on capillary electrophoresis (CE), Cari Zenger of Contisto shared a systematic overview of this powerful technique. "CE combines speed, quantitation, reproducibility, and automation with the very high resolving properties that electrophoresis already had," explains Zenger.
By leveraging the motion of charged particles in an electric field, CE offers an automated, high-efficiency alternative for separating everything from tiny ions to large biological complexes.
The Evolution to the Capillary Format
The phenomenon of electrophoresis—the migration of charged particles under the influence of an electric field—has been observed for over two centuries. Early iterations relied on paper or gel stabilizing media. While these successfully separated proteins and DNA, they struggled with quantitation and excessive Joule heating when high voltages were applied.
The breakthrough came in 1981, when Jim Jorgenson used narrow-bore fused-silica capillaries as the separation channel. Because these tiny tubes dissipate heat incredibly well, stabilizing media are no longer required, and analysts can apply very high voltages. Furthermore, fused silica is UV-transparent, allowing the capillary itself to act as the detector cell and generating a measurable peak pattern just like a liquid chromatograph.
Working in analytical science?
Register for a FREE Separation Science account to subscribe to the Separation Science Newsletter.
The Core Advantages of CE
According to Zenger, transitioning to a narrow capillary format provides laboratories with a unique array of analytical and operational benefits:
- Superior separation efficiency: CE produces remarkably narrow peaks by enabling the application of high voltages without system overheating, occasionally reaching a million theoretical plates in a single run.
- Extensive range of applications: Capillary systems can evaluate everything from small cations and drugs to complex entities like viruses and whole cells, whereas traditional gel electrophoresis is mostly limited to proteins and nucleic acids.
- Low sample requirement: Since a typical 50-centimeter capillary only contains approximately 1 microliter, sample injections are limited to the nanoliter scale.
- Unmatched separation efficiency: As high voltages can be applied without overheating the system, CE generates exceptionally narrow peaks, sometimes achieving up to a million theoretical plates on a single run.
- Minimal sample consumption: A standard 50-centimeter capillary holds only about 1 microliter, so sample injections are strictly in the nanoliter range.
- Broad application range: While standard gel electrophoresis is largely restricted to DNA, RNA, and proteins, capillary instruments can analyze tiny cations, small-molecule drugs, and incredibly large, complex materials, such as whole cells and viruses.
These combined benefits make CE a highly versatile, cost-effective option. "Electrophoresis is typically something that you are performing in an aqueous environment, which also reduces the amount of solvents being used," adds Zenger, highlighting its environmental benefits.
Complementing Chromatography
To fully appreciate CE, analysts must understand how it differs from techniques like high-performance liquid chromatography (HPLC). In chromatography, separation relies heavily on partitioning and the physical affinity between an analyte, a mobile phase, and a stationary phase.
Electrophoresis abandons the stationary phase entirely. Instead, separation is based strictly on differences in analyte mobility as charged compounds migrate through an electric field. "Because these two mechanisms are so fundamentally different, we can state that chromatography and electrophoresis are two different, complementary techniques," asserts Zenger.
When a laboratory obtains similar quantitative results from two completely different chemical mechanisms, confidence in the analytical data increases enormously. "Anybody involved in characterization is always happy with another tool in a toolbox," she remarks.
Essential CE Terminology
Before running an analysis, chemists must understand the unique vocabulary that separates CE from standard liquid chromatography:
- The electropherogram: This is the CE equivalent of a chromatogram, in which the observed peaks represent physical bands or zones of analytes migrating past the detector window.
- Migration time: Instead of retention time, analysts track migration time to determine the exact duration it takes for an analyte to travel from the injection point to the detection window.
- Analyte mobility: This is a core compound property that describes how quickly a specific molecule moves in response to the applied electric field.
- The normal mode setup: In standard CE operation, the anode is connected to the high-voltage source, while the cathode is connected to ground.
Mastering these foundational terms ensures scientists can accurately interpret their analytical data and troubleshoot their electrophoretic methods when necessary.
Efficiency Versus Selectivity
Ultimately, resolving two compounds requires a balance of selectivity and efficiency. Liquid chromatography is generally considered a low-efficiency, high-selectivity technique, relying heavily on complex column chemistries and precisely blended mobile phases to resolve peaks.
Capillary electrophoresis flips this dynamic entirely. CE operates as a high-efficiency, low-selectivity technique. Because the peaks generated by CE are so incredibly narrow and concentrated, analysts can achieve baseline resolution even when the actual selectivity differences between two compounds are extremely small. "If you have a high efficiency, you often can do with a lower selectivity to obtain resolution," points out Zenger.
Furthermore, these highly concentrated bands naturally amplify the signal reaching the detector. "Highly efficient peaks make for better detection properties in your separation window," she adds.
By understanding this core difference, analytical laboratories can strategically deploy CE to solve complex separation challenges that traditional chromatography simply cannot handle.
