Shimadzu Scientific Instruments announces the LCMS-8065XE, the latest evolution in triple quadrupole mass spectrometry. This new instrument introduces innovative technologies that deliver exceptional performance with evolved, efficient, and exact capabilities, redefining analytical excellence with world-class sensitivity, efficiency, and sustainability.
Technological Advancements in Ionization and Throughput
- StreamFocus ionization technology: The LCMS-8065XE features a low-dispersion nebulizer nozzle that dramatically reduces liquid droplet dispersion and maximizes ion-intake efficiency. This breakthrough reduces nebulizer gas consumption by up to 7-fold compared to conventional ESI sources and achieves exceptional sensitivity improvements, particularly in negative mode.
- Enhanced IonFocus performance: The evolved IonFocus unit utilizes a focusing electrode to selectively guide ions into the intake port while excluding neutral matrix components. This ensures sensitivity even when the ion spray sits further from the intake port, delivering superior robustness for long-term analysis.
- UFsweeper™ IV collision cell: The next-generation collision cell features a larger inlet lens diameter and an increased number of lenses for improved ion throughput, enhanced ion transmission, and dramatically improved sensitivity and quantitative precision.
Exceptional Analytical Performance and Ultra-Fast Speed
The LCMS-8065XE demonstrates remarkable capabilities, achieving sub-ng/L detection limits for PFAS compounds in drinking water via direct injection. The system delivers a 3- to 48-fold increase in sensitivity compared to previous-generation instruments while maintaining exceptional stability. It retains over 85% of initial response after more than 10,000 consecutive injections of complex wastewater samples (RSD <7%).
The instrument incorporates Shimadzu’s complete Ultra Fast Mass Spectrometry (UFMS) technology suite:
- World-class 5 msec positive/negative ion switching with zero signal loss.
- Ultra-fast MRM acquisition up to 555 channels/sec.
- Scanning up to 30,000 u/sec with maximum ion transmittance.
- Advanced UF-Qarray™II & UF-Lens™ II ion guides for maximum transmission efficiency.
AI-Powered Intelligence and Sustainability Leadership
The LCMS-8065XE leads in environmental responsibility with a 31% power consumption reduction through an intelligent Ecology Mode and 63% lower running costs compared to competitive systems (1,140W with dry pump option). The system features quick maintenance without breaking vacuum, ensuring minimal downtime.
For smart lab operations, Performance Concierge automatically monitors system performance, provides proactive maintenance alerts, and reduces instrument downtime through predictive diagnostics. Additionally, Peakintelligence for LCMS delivers revolutionary AI-driven peak detection with up to a 67% reduction in manual review time and superior reproducibility across complex analyses.
Comprehensive PFAS Analytical Solution and Availability
The FluoroSuite provides a complete PFAS analysis solution, featuring an optional PFAS Analysis Kit for minimized background contamination, low-adsorption Shim-vial™ consumables, and support for EPA methods (533/537.1/1633), ASTM 8421, and ISO21675 regulatory methods. Integration with LabSolutions Insight™ enables automatic method optimization and intuitive workflow management.
The LCMS-8065XE excels across environmental monitoring, food safety, pharmaceutical analysis, clinical research, and industrial quality control applications. The instrument is available immediately through Shimadzu’s North American network with comprehensive applications development, training, and service support.
