Getting tissue sectioning for MS imaging right rarely gets the attention it deserves — it looks like routine histology, and mostly is not. Several habits that are entirely correct for diagnostic pathology are actively harmful here, and the most common one is invisible until the mass spectrometer reports it.
Key Takeaways
|
Why Sectioning Habits Need Unlearning
General histology optimises for morphology under a microscope, and several of its standard practices are simply wrong for a technique that will subsequently ionise the tissue directly. The clearest example is embedding.
OCT Is Not Compatible With MALDI Imaging Optimal cutting temperature compound is the default embedding medium in diagnostic and research histology, and it is directly incompatible with mass spectrometry imaging. Published cryostat guidance for MALDI states the position without qualification: only cryosections are suited for MALDI imaging, and the tissue must not be embedded in OCT, because OCT contains polymers that are detected in the mass spectrometer and these polymer signals may suppress the analyte signal completely. The same guidance notes that homogeneous tissue such as brain, liver, kidney, and tumours can generally be cut to sufficient quality without any embedding at all, while loosely structured samples, such as whole zebrafish, need support and should be embedded in an MS-compatible alternative such as gelatin or carboxymethylcellulose rather than OCT. Anyone arriving from routine histology should treat the embedding step as one to actively reconsider rather than carry over by habit. |
The same source notes a related practical point: freezing tissue directly in liquid nitrogen usually makes it brittle and difficult to section cleanly, and for routine work freezing in a standard freezer or within the cryostat itself is generally sufficient. That is worth knowing before assuming faster freezing is always better; for sectioning quality specifically, it is not, even though rapid freezing remains critical for preserving labile metabolites, as covered in FFPE vs. Fresh Frozen for Mass Spectrometry Imaging.
Working in analytical science?
Register for a FREE Separation Science account to subscribe to the Separation Science Newsletter.
What Section Thickness Should You Use?
There is no single correct answer, and stating one would be false precision. What matters is understanding what thickness trades against, and then checking where published work on comparable tissue has landed.
Thicker sections increase signal, since more material is available per pixel, and correspondingly increase the amount of tissue a laser or solvent spot must penetrate, which raises delocalisation risk and can complicate matrix crystal formation. Thinner sections reduce both, at the cost of sensitivity for low-abundance species.
Study or Guidance | Tissue | Thickness Used | Note |
Reproducibility study of tryptic peptide imaging | Murine brain | 12 microns | Cryosectioned at −22°C chamber and object temperature |
Conductive adhesive film comparison | Multiple, including bone and whole small organisms | 5, 10, and 20 microns tested | Signal was thickness-independent only with the conductive film, not with standard ITO glass |
Adipose tissue lipid imaging protocol | Human infrapatellar fat pad | 15 microns | Cut below −30°C specifically to manage tissue melting during sectioning |
Lens crystallin imaging | Bovine and rabbit ocular lens | 12 microns | Sectioned at −20°C on a disposable-blade cryostat |
General cryosectioning guidance | Homogeneous organs: brain, liver, kidney, tumour | Not fixed; varies with study aim | These tissues section well without embedding at standard settings |
Table 1. Section thickness and cryostat temperature actually used in published imaging work. The range, not any single value, is the useful information; select within it based on your tissue’s handling behaviour and your target analyte’s abundance.
Fatty or lipid-rich tissue is the case most likely to need a colder chamber than instinct suggests. The adipose tissue protocol above specifically used a chamber temperature below −30°C to manage tissue melting during cutting, well colder than the −20 to −22°C common for brain or lens tissue. Melting during sectioning does not merely spoil one section; it can smear material and compromise adjacent sections cut afterward on the same blade, so identifying a difficult tissue and adjusting temperature before cutting begins is worth the pause.
Cryosectioning Technique
Beyond thickness and temperature, four practical details recur across published protocols and are worth building into a standard operating procedure.
- Clean the blade between different tissues or blocks. Published guidance specifically recommends cleaning the cryostat blade with ethanol to remove OCT residue before cutting an unembedded or differently embedded sample, since carryover contamination is otherwise easy to miss.
- Match chamber and object temperature to the tissue, not to habit. A setting that works well for brain will not necessarily suit fat, bone, or a whole small organism, as the thickness table above illustrates.
- Handle the section by the slide, not the tissue. Once mounted, excess embedding or OCT residue at the tissue edge is conventionally removed with a swab briefly dipped in 70 percent ethanol, applied carefully, since excessive force at the tissue margin can detach or tear it from the slide.
- Photograph the section before and after each major step. Published reproducibility work builds an optical image checkpoint into the workflow after mounting and again after washing, digestion, matrix application, and acquisition, specifically to catch tissue loss or damage before it is discovered too late to recover.
Conductive Slides and a Limitation Worth Knowing
Conductivity is required because the tissue surface must be part of the electrical circuit that extracts ions into the mass spectrometer — glass alone does not conduct. The near-universal solution is indium tin oxide coated glass, and it has a documented limitation that most protocols do not mention.
Standard ITO Glass Loses Effectiveness Through Thick Tissue Work developing a conductive adhesive film alternative states the problem plainly: signal intensities obtained with ITO glass slides were affected by tissue thickness, because conductivity is lost through thicker sections, and the strength of conductivity may also depend on how tightly the tissue adheres to the slide surface. The film alternative was tested directly against this limitation. Signal intensities for small molecules were similar across 5, 10, and 20 micron sections when the conductive adhesive film was used, and quantified average intensity in a defined region showed thickness had no material effect with the film, in contrast to the documented thickness dependence on standard ITO glass. The film also offers stronger adhesion at low temperature and has been demonstrated on bone, muscle, adipose tissue, and whole small organisms including mice and fish, tissue types that are traditionally difficult to section and mount well. |
The practical takeaway is not that ITO glass is wrong for routine use; it remains the standard for good reason and works well for typical thin sections of homogeneous tissue. The point is narrower and more useful: if your tissue is thick, mechanically difficult, or structurally heterogeneous, a thickness-dependent signal loss on standard slides is a documented and specific failure mode rather than a vague possibility, and a conductive film is a validated alternative worth testing rather than a niche curiosity. Checking that a slide is actually conductive before use, with a simple multimeter continuity check, is a five-second step that prevents a wasted run.
Thaw-Mounting Without Delocalisation
The moment a frozen section touches a room-temperature slide, its water content begins to redistribute, and how that moment is handled determines whether small molecules stay where they were.
Published protocols converge on a consistent sequence.
- Mount by touch, not by pressure. A conventional thaw-mount technique brings a room-temperature conductive slide into brief contact with the frozen section, relying on the temperature differential to transfer the section rather than applying pressure that risks smearing it.
- Dry under vacuum before proceeding. Published protocols specify vacuum desiccation for roughly 30 to 60 minutes depending on section thickness and dimensions, removing surface moisture from the thaw-mounting process that would otherwise allow analytes to migrate before matrix application.
- Avoid condensation on rewarming. Guidance for related workflows specifically warns against letting condensation form on the sample surface during the thaw-to-vacuum transition, and against releasing vacuum before the system has warmed enough that atmospheric moisture will not condense onto the cold sample.
Skipping or rushing the desiccation step is a common and avoidable source of poor reproducibility, precisely because its absence does not look like an error. A delocalised distribution looks like a biological finding rather than an artefact, which is the same trap discussed for washing and staining steps elsewhere in this section, and in Sample Preparation for Spatial Analysis: From Tissue to Data.
Storage Before Analysis
Sections do not have to be analysed immediately, and how they are stored in the meantime affects what survives to be measured.
Three practices recur across published work.
- Freeze-mount sections at −80°C for interim storage. This is standard across the cited protocols and prevents ongoing enzymatic and chemical change between mounting and analysis.
- Dry thoroughly before removal from cold storage. The same desiccation logic that applies immediately after thaw-mounting applies again after removal from long-term storage, since moisture reforms during warming.
- Minimise freeze-thaw cycles. Each thaw reintroduces the moisture-migration risk that desiccation was meant to control. A section stored, thawed for imaging, and returned to storage for a later repeat should be treated cautiously rather than assumed equivalent to a fresh mount.
None of these storage practices are exotic; the discipline is simply in applying them consistently rather than treating a mounted slide as inert once it is in the freezer. For the matrix or solvent decision that follows sectioning, and how deposition method interacts with the resolution achievable on a given section, see MALDI Imaging Mass Spectrometry: How It Works and the resolution arithmetic in Spatial Resolution vs. Sensitivity in MS Imaging: The Fundamental Trade-off. For the wider preparation sequence this fits within, see Sample Preparation for Spatial Analysis: From Tissue to Data, and for the fixation decision that precedes it, FFPE vs. Fresh Frozen for Mass Spectrometry Imaging. Matrix application technique and its own resolution implications are covered in Matrix Selection and Application in MALDI Imaging.
