Unveiling Hidden Contaminants: TD-GC-MS Workflows for PFAS Migration in Food Contact Materials

Executive Summary: Key Takeaways for Method Developers

The following points summarize the critical shifts and technical requirements for analyzing modern food packaging:

• The Shift: 2026 regulations are moving focus from agricultural products to Food Contact Materials (FCMs).
• The Gap: Standard LC-MS/MS methods often miss neutral, volatile PFAS like FTOHs and FASAs.
• The Solution: Direct TD-GC-MS provides a completely solventless, derivatization-free workflow, achieving low-picogram (pg) detection limits of volatile and polar migrants.
• Optimization: Success requires managed thermal desorption to prevent thermolysis, the addition of sodium hydroxide (NaOH) to prevent on-tube esterification, and dual EI/CI ionization for structural confirmation.

These foundational insights help laboratories transition toward more comprehensive volatile PFAS screening protocols.

The 2026 Regulatory Landscape for Food Packaging

The global food safety landscape is no longer just about analyzing agricultural products; in 2026, the microscope is aimed squarely at packaging. Driven by massive regulatory updates—such as the Government of Canada's March 2025 Risk Management Approach for PFAS (excluding fluoropolymers) under the Canadian Environmental Protection Act, 1999 (CEPA)—analyzing chemical migration from Food Contact Materials (FCMs) is now a paramount priority for contract testing laboratories.

This strategic policy framework mandates a phased prohibition of the PFAS class based on product category, exposure risk, and alternative availability:

• Phase 1 (Spring 2027 proposed regulation): Targets the prohibition of unregulated PFAS in firefighting foams.
• Phase 2 (2027 consultation): Targets consumer-facing applications, explicitly prohibiting PFAS in cosmetics, textiles, consumer food packaging materials, food additives, and non-industrial food-contact products such as paper plates, bowls, and cups.
• Phase 3 (Timeline TBD): Evaluates critical sectors where feasible alternatives are not yet established, deferring heavy industrial food contact materials and fluorinated gases for later regulatory assessment.

This tiered regulatory timeline demands immediate analytical adaptation from food packaging manufacturers and commercial testing laboratories.

Under overarching framework rules like Regulation (EC) No 1935/2004, FCMs are legally prohibited from transferring constituents to food in quantities that could endanger human health. Compliance limits are tightening globally, as illustrated by these key regulatory metrics:

• Overall Migration Limit (OML): Established at 10 mg/dm² for plastic packaging materials under Commission Regulation (EU) No 10/2011.
• Tolerable Weekly Intake (TWI): Restricted to a combined threshold of just 4.4 ng/kg bw/week by the European Food Safety Authority (EFSA) for four critical compounds: PFOA, PFNA, PFHxS, and PFOS.

These stringent safety thresholds require analytical instruments capable of reliable trace-level detection. Per- and polyfluoroalkyl substances (PFAS) have been used since the mid-20th century to confer essential greaseproof and non-stick properties to paper coffee cups, fast-food wrappers, and microwave popcorn bags. However, through mechanical stress, heat exposure, and lipophilic interactions with food matrices, volatile and semi-volatile PFAS readily migrate from the substrate into the consumable.

Working in analytical science?

Register for a FREE Separation Science account to subscribe to the Separation Science Newsletter.

Subscribe for free

The Blind Spot in Liquid Extraction

Historically, laboratories have relied on solvent-heavy extraction followed by LC-MS/MS [2]. While effective for ionic species, this approach fundamentally fails to capture neutral and volatile PFAS, such as the following classes:

• Fluorotelomer alcohols (FTOHs)
• Perfluoroalkane sulfonamides (FASAs)
• Perfluoroalkane sulfonamide ethanols (FASEs)

The inability to detect these compounds leaves a significant gap in risk assessment data for food safety experts. These neutral "forever chemicals" represent a massive toxicological blind spot. Furthermore, solvent-intensive extractions are time-consuming and often introduce laboratory background contamination that can mask ultra-trace analytes. To overcome these hurdles, analytical method developers are increasingly adopting thermal desorption-gas chromatography-mass spectrometry (TD-GC-MS).

Mechanics of TD-GC-MS in FCM Analysis

Thermal desorption (TD) bypasses solvents entirely, reducing sample preparation time and the risk of contamination. In this workflow, a representative sample of the FCM is placed into a TD tube and subjected to controlled, progressive heating under inert carrier gas. This process desorbs volatile PFAS—including short-chain perfluorocarboxylic acids (PFCAs)—from the complex polymer or paper matrix [2].

The analytes are focused onto a Peltier-cooled cold trap, which is then flash-heated, injecting a highly concentrated band directly into the GC-MS system. This solventless preconcentration enables laboratories to achieve limits of detection (LODs) in the ultra-trace, low-picogram (pg) range, meeting the stringent requirements of 2026 safety standards [2].

Advanced Workflow Optimization Strategies

Device Selection and Deactivation Protocols

When expanding workflows from controlled matrix spikes to real-world cookware samples, selecting and optimizing the thermal extraction apparatus is paramount. Recent instrumentation comparisons evaluate three distinct sampling devices for extraction at 250° C [3]:

• Micro-chamber/thermal extractor: While convenient, compact multi-chamber arrays suffer from significant background artifacts. High-temperature conditions stress the internal elastomer sealing rings, causing severe outgassing of matrix components and disrupting non-target volatile screening.
• Direct pan desorption: Utilizing a glass bell jar placed directly onto heated pans introduces temperature gradients. Volatiles often condense on cooler "cold spots" at the top of the glass dome (which drops to 150° C), causing non-linear recoveries for mid-chain targets.
• Thermal desorption oven: A custom glass-tube desorption oven provides optimal blank profiles and consistent recoveries (70-101%) across diverse target PFAS. Its primary advantage is that critical sealing rings remain entirely outside the heating block, preventing thermal stress and contamination.

Isolating the seals from the high-temperature zone ensures accurate screening of native migrant structures.

Regardless of device selection, severe target analyte loss occurs due to surface adsorption on glass components [3]. To guarantee high quantitative recovery, all system glassware must undergo strict silanization deactivation:

• Silylation clean: Soak pre-cleaned glass assemblies in a 5% dimethyldichlorosilane (DMDCS) solution in toluene for 15 minutes.
• Thermal conditioning: Rinse thoroughly with toluene and methanol, dry at ambient temperature, and purge under inert nitrogen at 200 °C for 1 hour, then at 300 °C for another 1 hour.

This chemical transformation completely blankets active silanol sites, yielding a highly hydrophobic surface that eliminates analyte retention.

Direct, Derivatization-Free TD-GC-MS: Bypassing the Derivatization Step

Historically, gas chromatographic analysis of polar PFCAs was considered highly challenging due to the polarity of the carboxylic acid group, which leads to severe peak tailing and adsorption at active sites in GC inlets and on stationary phases. To bypass this, laboratories traditionally relied on complex, solvent-heavy chemical derivatization techniques to convert these acids into volatile, non-polar forms prior to GC injection. However, recent method developments have demonstrated that TD-GC-MS can successfully analyze a wide spectrum of polar PFCAs (C₄-C₁₈) and highly polar PFECAs without any prior chemical derivatization [2].

eBooks

Food & Beverage Insights: Reliable Methods for Quality, Safety, and Compliance

Find solutions to meet the most demanding food and beverage testing requirements, and discover proven workflows, regulatory compliance strategies, and the technologies that make them possible.

Read More

To successfully perform direct analysis of polar PFAS without derivatization, the method relies on several critical analytical parameters:

• Prevention of on-tube esterification: NaOH (4 equivalents) must be added to the methanolic standard solutions containing carboxylic acid groups. This addition neutralizes the free acids on the sorbent, thereby completely preventing unwanted solvent-induced methyl ester formation during desorption.
• Selective solvent removal: After injecting the standard solutions onto inert adsorption tubes (packed with Tenax TA, Carbograph 1TD, and Carboxen 1000), the tubes are dry-purged with nitrogen at a flow rate of 50 mL/min for 2 to 10 minutes to completely evaporate the methanol.
• Controlled thermal extraction: The dry tubes are desorbed at 280 °C for 10 minutes in the thermal desorption unit, and the analytes are focused onto an Air Toxics cold trap at 25 °C. The trap is then flash-heated to 300 °C for 5 minutes for split injection (1:10).
• Fluorinated stationary phase: Chromatographic separation is performed on a crossbonded trifluoropropylmethyl polysiloxane film column (such as a Restek Rtx-200MS, 30m ∗ 0.25mm, 1.00 μm film thickness), which provides the unique selectivity required to elute polar fluorine compounds with minimal peak tailing and column bleed.

This optimized sequence enables quantitative recovery of polar PFAS directly from the solid matrix without chemical modification.

Applying this validated method to commercial consumer products reveals critical real-world migration profiles and structural changes:

• Long-chain PFCA trailing: Direct thermal extraction of commercial baking trays reveals a distinct, repeating migration footprint of native, long-chain PFCAs extending up to C₂₃ at concentrations reaching 34 ng/dm² [3].
• Polyfluoroether surfactant thermolysis: Testing polymer linings formulated with complex-processing surfactant aids yields no native acid peaks. Instead, the chromatograms selectively track a full series of corresponding polyfluoroether hydrides, confirming complete decarboxylation during the high-temperature industrial sintering process [3].
• Non-target volatile profiling: Broad-spectrum scanning simultaneously uncovers up to 175 non-target volatile organic compounds (VOC) leaching from standard coatings—including a full series of linear alkanes, aldehydes, and aromatic siloxanes—at levels below 10 μg/ dm² [3].

Capturing these target and non-target thermolysis components provides a comprehensive representation of real-world food contact exposure risks.

This direct, non-derivatized analysis delivers exceptional sensitivity, with LODs in the ultra-trace range:

• PFCAs: Achieves on-instrument LODs of 1-4 pg in EI mode, 1-9 pg in PCI mode, and 0.3-15pg in NCI mode, with the sole exception of short-chain PFBA, which has an LOD of 142pg in NCI due to atypical fragmentation behavior [2].
• FTOHs: Yields LODs of 5-30 pg on-column, with PCI providing the most sensitive response due to the high ionization efficiency of hydroxyl groups in positive chemical ionization [2].
• Monodisperse PFECAs: Achieves limits of 2-40pg for branched and linear species like GenX, and Adona. Linear APFDO elutes with an LOD of 300 pg in EI, while bC₁₇O₅H(TFEE₅) achieves 1-70 pg [2].

These picogram-level detection limits demonstrate that direct thermal desorption is highly competitive with traditional derivatization methods.

Mass Spectrometry: Ionization and Parameters

Structural confirmation is critical, as many emerging volatile contaminants lack definitive spectral database entries. A dual-ionization approach is the current gold standard, utilizing two distinct operational modes:

• Screening (EI): Use 70 eV Electron Impact ionization for initial group-specific SIM fragment detection, selecting m/z 131 for PFCAs, m/z 95 for FTOHs, and m/z 69 for PFECAs [2].
• Confirmation (CI): Cross-reference with Chemical Ionization (CI) in SIM mode to preserve and verify the delicate molecular ion (e.g., tracking the [M+H]+ ions of FTOHs in PCI, or the homologous series [M-F]- of PFCAs in NCI) [2].

This combined ionization setup delivers both maximum diagnostic sensitivity and unambiguous qualitative identification.

Beyond TD: Automated Liquid Extraction and Micro-SPE for High-Throughput

For high-volume contract labs, manual TD tube packing is often a bottleneck. Automated solvent extraction and micro-solid-phase extraction (micro-SPE), coupled with GC-TQ (triple quadrupole GC/MS), provide a high-throughput, liquid-injection alternative for screening programs.

By integrating robotic liquid-handling platforms with a triple quadrupole gas chromatograph-mass spectrometer (GC-MS/MS) system, labs can automate the entire preparation sequence directly from heated packaging samples. This high-throughput process follows a highly optimized, automated path [4]:

• Automated extraction: Spikes cut food contact samples (1 g) with isotopically labeled internal standards (istd), automatically adds 4 ml of ethyl acetate (ea), and performs heating-assisted vortexing and incubation.
• Clean-up and filtration: Moves the extract to a tray cooler, centrifuges the vials, and passes the supernatant through an online micro-spe cartridge to eliminate matrix interferences.
• Direct liquid injection: Automatically injects a 3 microliter aliquot of the filtered extract directly into a standard gas chromatograph equipped with a 624-type capillary column (30 m x 0.25 mm, 1.40 micrometer), bypassing the need for manual evaporation and reconstitution.

This fully automated configuration drastically minimizes sample turnaround times and eliminates manual pipetting errors.

By executing this automated sequence on paper coffee cups, laboratories can target more than 30 volatile pfas compounds, achieving the following performance metrics [4]:

• Method detection limits (MDLs): Achieve ultra-trace sensitivity of less than or equal to 1 microgram per kilogram (ppb) for 25 target analytes, and less than or equal to 2 microgram per kilogram for six targets.
• Intrabatch precision: Achieves relative standard deviations (RSDs) of recoveries less than or equal to 17% across three quality control (QC) levels (low, mid, and high concentration spikes).

Conclusion

By adopting hyphenated, solventless GC workflows—whether through TD or automated solvent micro-SPE extraction—analytical laboratories can stay ahead of the aggressive 2026 regulatory curve. These methods offer the sensitivity and specificity required to accurately capture the true volatile migration risk inherent in modern food-contact materials.

References

1. Environment and Climate Change Canada & Health Canada. (2025). Risk Management Approach for Per- and polyfluoroalkyl substances (PFAS), excluding fluoropolymers. Government of Canada. Available at: https://www.canada.ca/en/environment-climate-change/services/evaluating-existing-substances/risk-management-approach-per-polyfluoroalkyl-substances.html

2. Wolf, N., Müller, L., Enge, S., Ungethüm, T., & Simat, T. J. (2024). Thermal desorption - gas chromatography - mass spectrometry (TD-GC-MS) analysis of PFAS used in food contact materials. Food Additives & Contaminants: Part A, 41(9), 1099–1117. DOI: 10.1080/19440049.2024.2370371. Available at: https://www.tandfonline.com/doi/full/10.1080/19440049.2024.2370371

3. Wolf, N., Müller, L., Enge, S., Ungethüm, T., & Simat, T. J. (2024). Analysis of PFAS and further VOC from fluoropolymer-coated cookware by thermal desorption-gas chromatography-mass spectrometry (TD-GC-MS). Food Additives & Contaminants: Part A, 41(12), 1663–1678. DOI: 10.1080/19440049.2024.2406007. Available at: https://www.tandfonline.com/doi/full/10.1080/19440049.2024.2406007

4. Lim, G., Wong, A., Zhang, Y., & Zou, A. (2025). Fully Automated Workflow for Volatile PFAS Analysis in Food Contact Materials Using GC-Triple Quadrupole MS. Agilent Technologies / CTC Analytics AG Application Note 5994-8295EN. Available at: https://www.agilent.com/cs/library/applications/an-volatile-pfas-gc-tq-5994-8295en-agilent.pdf
